MBD

Why Choose SolidWorks MBD ?

SOLIDWORKS® Model-Based Definition (MBD) lets you define and organize 3D dimensions, tolerances, datums, notes, Bills of Material (BOMs), and other annotations; customize publishing templates for manufacturing, such as Part or Assembly Specifications, Request for Quote (RFQ), and Incoming Inspection Reports. You can also publish to widely accepted formats, such as eDrawings®, STEP 242, and 3D PDF for clear 3D communications.

For easier adoptions of the model-based practices, several convenient capabilities have been included in every seat of SOLIDWORKS Standard. With SOLIDWORKS Standard, you can annotate a 3D part or assembly, organize the 3D definitions with annotation views and communicate in eDrawings all directly in 3D.


Discover the Features

  • Define 3D Annotations
  • Organize 3D Annotations
  • Publish 3D Data with Annotations and Views
  • Minimize Scrap and Rework
  • Eliminate Time-to-market Delays
  • Reduce Service Costs
Ask Price Now
