What is VISI Reverse?
VISI Reverse is an advanced module within HEXAGON’s VISI CAD/CAM suite, purpose-built to transform 3D scan data into editable, manufacturing-ready CAD models. By combining powerful hybrid modeling capabilities with robust scan data processing tools, VISI Reverse provides a direct shortcut from physical part or prototype to digital design and production—streamlining everything from time-intensive reconstruction to seamless mold and stamping integration.
VISI Reverse
Key Features
- Direct Point Cloud Import: Instantly import large point clouds directly from 3D scanning devices, such as HEXAGON’s Absolute Arm or Leica Absolute Tracker, as well as generic CSV formats.
- Automatic Mesh Creation & Refinement: Create and clean up triangle meshes automatically, with tools for smoothing, gap filling, mesh repair, and refinement to improve scan quality.
- Dynamic Wireframe & Surface Generation: Effortlessly construct wireframe grids and generate precise surfaces from mesh boundaries—enabling a smooth transition from point cloud to solid, editable geometry.
- Powerful Filtering & Optimization: Apply advanced algorithms for filtering, noise reduction, redundancy elimination, and efficient point or mesh management.
- Semi-Automatic Editing Functions: Accelerate tasks like hole filling, curvature examination, and mesh segmentation for clean, watertight models ready for downstream CAD/CAM workflows.
- Portable Device Compatibility: Designed to import data from Hexagon’s full line of measuring arms and laser scanners for maximum accuracy in real-world manufacturing settings.
- History and Legacy Model Integration: Easily scan, archive, reuse, adapt, or improve upon prototypes or existing models—making it easy to start every new project from physical inspiration or legacy designs.
Benefits
- Significant Time Savings: Reduce weeks of manual model building and error-prone conversions to just a few hours or days—streamlining the process from scanning to manufacturing.
- Seamless CAD/CAM Integration: VISI Reverse models slot directly into VISI’s Mold or Stamping Die workflows, enabling rapid tool creation, modification, and documentation.
- Design Flexibility: Ideal for creating customized, perfectly fitting replacement parts, revising worn or broken components, or innovating on top of existing products.
- Enhanced Data Quality: Reliable mesh repair and processing tools guarantee clean, accurate geometry—supporting everything from toolpath generation and simulation to inspection and prototyping.
- Direct Manufacturing Application: Models can be sent straight to production for prototyping, mold creation, rapid casting, or customized part manufacturing without iterative rework.
How VISI Reverse Works
- Scan the Part: Use portable measuring arms or 3D laser scanners to capture the part’s surface, generating high-density point cloud data.
- Process & Clean: Import, merge, and optimize the point cloud—remove noise, fill gaps, and refine mesh quality.
- Create Surfaces: Leverage automatic or guided surfacing tools to turn mesh segments into NURBS surfaces and complete CAD geometry.
- Edit, Analyze & Output: Adjust with standard CAD commands, segment models, and output in a range of popular formats for direct manufacturing or further design work1234.
Why Choose VISI Reverse?
- All-in-One Solution: Integrates every reverse engineering step—scanning, data clean-up, mesh/surface creation, editing—within one module.
- Manufacturing-Driven Design: Built for users in mold, die, stamping, and production environments, supporting every step through to finished parts.
- Support for Any 3D Scanner/Format: Handles a wide range of input devices and file types, with tools for merging, aligning, and comparing scan data.
VISI Reverse
Real-World Applications
- Mold & Die Making: Rapidly create core/cavity models from legacy tooling or prototypes.
- Repair & Replacement: Digitally reconstruct broken, worn, or missing parts for quick reproduction.
- Product Development: Adapt and improve on physical prototypes or legacy products for new designs.
- Reverse Engineering: Generate CAD from hand-made, cast, or scanned parts—critical when no digital file exists.
- Quality Inspection: Use scan-to-CAD models for comparison, simulation, and manufacturing validation.
